10dB (10:1) Tapper 350-5930MHz 500W 7-16 -161dBc
TESSCO SKU: 543176
MFG PART #: DN-74FD
Sign In or Register for preferred pricing!
Added To Cart
MICROLAB's DN-x4FD series of tappers unevenly split high power cellular signals in fixed ratios from 1000:1 – 2:1 with minimal reflections or loss over the key wireless bands in the range 350 – 5,930 MHz, (there is no coupling 1550 – 1650 MHz). The innovative asymmetric design ensures an excellent input VSWR and coupling flatness across the specified bands, even down to a 2:1 split. The lightweight design allows easy attachment to a wall using the supplied bracket. Designed with only a few solder joints and an air dielectric, loss is minimized and reliability enhanced. See DN-x4FN, and DN-x4FE series for similar tappers with N, and 4.3-10 connectors.
