150-160 MHz Mobile Duplexer

  • TESSCO SKU: 211112
  • QTY/UOM: 1 EACH
  • UPC: 646444433990
  • MFG PART #: 64316-0/MC(5B)

EMR 150-160 MHz mobile duplexer. 50 W, 70dB isolation, 4.6-6 MHz sep., 1.2dB max insert loss. N/F termination. TESSCO Tuned. Not field tunable

Related Media

Technical Specs

  • Item Length
    8.5 in
  • Item Height
    1-3/8 in
  • Item Width
    6-1/8 in
  • Operating Temperature Range
    -30-60 deg C
  • Insertion Loss (Tx/Ant-dB)
    1.2
  • Minimum Isolation
    70 dB
  • Qty/ Uom
    1 Each
  • Minimum Separation
    4.6 MHz
  • Tuning Method
    TESSCO Tune
  • Frequency Range
    150-160 MHz
  • Number of Cavities
    6
  • RF Connectors
    N Female
  • Insertion Loss (Rx/Ant-dB)
    1.2
  • Maximum VSWR
    1.25:1
  • Maximum Power Input
    50 W
  • Manufacturer
    EMR Corporation
