Sabre Communications
1800TLWD 230-ft Guyed Tower Kit
NCNR
TESSCO SKU: 336002
UPC: 336002
QTY/UOM: 1/each
MFG PART #: C05-002-052

The Sabre Site Solutions C05-002-052 1800 TLWD Guyed Tower Kit comes complete with all of the hardware you need to construct a 230-ft guyed tower. All components are hot-dip galvanized for years of worry-free corrosion protection in even the harshest environments. Included with your complete C05-002-052 1800 TLWD Guyed Tower Kit:BRBR(23) 1800 TLWD standard 10-ft tower sectionsBR(9) Bolt assemblies, ½-in-13 × 1 ¾-inBR(207) Bolt assemblies, ½-in-13 × 2-inBR(18) U-bolt assemblies, ½-in-13BR(36) Bent bolt assemblies for guy bracketBR(6) Jaw and eye turnbuckle, ½-in × 12-inBR(12) Jaw and eye turnbuckle, ¾-in × 12-inBR(18) Shackle screws, ⅝-inBR(30) Heavy-duty open thimbles, ⅜-inBR(6) Heavy-duty open thimbles, ½-inBR(3) Wire rope clips, ¼-inBR(12) Dead-end sleeves (ice clips), ¼-inBR(18) Dead-end sleeves (ice clips), 5/16-inBR(6) Dead-end sleeves (ice clips), ⅜-inBR(12) Dead-end grips, ¼-inBR(18) Dead-end grips, 5/16-inBR(6) Dead-end grips, ⅜-inBR(1293-ft) EHS guy strand, ¼-inBR(2406-ft) EHS guy strand, 5/16-inBR(963-ft) EHS guy strand, ⅜-inBR(3) Leg capsBR(18) Guy bracketsBRBRNormal soil foundation designs are found below in the Attachments section. Geotechnical surveys are always recommended prior to any tower installation. If you would like for TESSCO to recommend a tower for your particular application, complete a A HREF="https://www.tessco.com/customer-service/forms/tower-design-request-form" target="_blank"TESSCO Tower Design Questionnaire/A. BRBRPurchasing a tower from TESSCO without submitting the questionnaire will be done at your own risk.
