Laird Connectivity, Inc.

2.4-2.5/5.15-5.9 GHz 4 Port H/V MIMO Antenna

  • TESSCO SKU: 516319
  • QTY/UOM: 1 EACH
  • UPC: 729198469948
  • MFG PART #: PDM245115H-FNF

The Laird PDM245115H-FNF is a four-port directional antenna for use in 802.11n MIMO applications. Designed for low sidelobe and front-to-back performance, the antenna is an excellent choice for high density Wi-Fi applications where adjacent antenna interference is of concern. It is equipped with two (2) vertically polarized ports and two (2) horizontally polarized ports. Enclosed in a compact and low-profile polycarbonate radome and equipped with an articulating arm that can be affixed to a mast or anchored directly to a vertical surface. The dual-band frequency coverage means that a single type of antenna can be deployed with any MIMO radio in the 2.4 – 2.5 GHz and 5.15 – 5.9 GHz bands.

Related Media

Technical Specs

  • Item Length
    20 in
  • Maximum VSWR
    2.0:1, 1.6:1
  • RF Connectors
    N Female
  • Antenna Mounting Style
    Wall
  • Polarization
    Vertical, Horizontal
  • Item Width
    14.5 in
  • Maximum Power
    1 W
  • Specific Frequency
    5150-5900 MHz, 2400-2500 MHz
  • Gain dBi
    14 dBi, 14.5 dBi
  • Vertical Beamwidth
    33 deg, 27 deg
  • Qty/ Uom
    1 Each
  • Item Weight
    5.1 lb
  • Jumper Included
    No
  • Manufacturer
    Laird Connectivity, Inc.
  • Horizontal Beamwidth
    31 deg
  • Item Height
    0.8 in
  • Color
    White
