Microlab/FXR

20dB (100:1) Tapper 137-960 MHz 500W Type N -161

  • TESSCO SKU: 581426
  • QTY/UOM: 1 EACH
  • UPC: 729198985127
  • MFG PART #: DN-01FN

Microlab DN-x1FN series of Tappers unevenly split high power RF signals in fixed ratios from 100:1 to 2:1 with minimal reflections or loss. The Tappers cover VHF, UHF, TETRA, and 700 - 900 MHz Public Safety bands. The innovative asymmetric design ensures an excellent input VSWR and coupling flatness across the specified bands. The lightweight design allows easy attachment to a wall using the supplied bracket. Designed with only a few solder joints and an air dielectric, loss is minimized and reliability enhanced. See DN-x4 series for similar Tappers with broader bandwidth and multiple connector options.

Technical Specs

  • Qty/ Uom
    1 Each
  • Frequency Range
    137-960 MHz
  • Maximum Power
    500 W
  • PIM Typical
    -161 dBc
  • Nominal Coupling
    20 dB
  • Manufacturer
    Microlab/FXR
  • RF Connectors
    N Female
