20dB (100:1) Tapper 350-5930MHz 500W 4.3-10 -161d

  • TESSCO SKU: 556529
  • QTY/UOM: 1 EACH
  • UPC: 729198870911
  • MFG PART #: DN-04FE

MICROLAB's DN-x4FE series of tappers unevenly split high power cellular signals in fixed ratios from 1000:1 – 2:1 with minimal reflections or loss over the key wireless bands in the range 350 – 5,930 MHz, (there is no coupling 1,550 – 1,650 MHz). The innovative asymmetric design ensures an excellent input VSWR and coupling flatness across the specified bands, even down to a 2:1 split. The lightweight design allows easy attachment to a wall using the supplied bracket. Designed with only a few solder joints and an air dielectric, loss is minimized and reliability enhanced. See DN-x4FN, and DN-x4FD series for similar tappers with N, and 7/16 connectors.

Related Media

Technical Specs

  • Frequency Range
    350-5850 MHz
  • Maximum Power
    500 W
  • Nominal Coupling
    20 dB
  • Maximum VSWR
    1.25:1
  • PIM Typical
    -161 dBc
  • RF Connectors
    4.3-10 Female
  • Qty/ Uom
    1 Each
  • Manufacturer
    Microlab/FXR
