20dB (100:1) Tapper 350-5930MHz 500W Type N -161

  • TESSCO SKU: 514318
  • QTY/UOM: 1 EACH
  • UPC: 729198433932
  • MFG PART #: DN-04FN

MICROLAB's DN-x4FN series of tappers unevenly split high power cellular signals in fixed ratios from 1000:1 – 2:1 with minimal reflections or loss over the key wireless bands in the range 350 – 5,930 MHz, (there is no coupling 1550 – 1650 MHz). The innovative asymmetric design ensures an excellent input VSWR and coupling flatness across the specified bands, even down to a 2:1 split. The lightweight design allows easy attachment to a wall using the supplied bracket. Designed with only a few solder joints and an air dielectric, loss is minimized and reliability enhanced. See DN-x4FD, and DN-x4FE series for similar tappers with 7/16, and 4.3-10 connectors.

Related Media

Technical Specs

  • Item Width
    2 in
  • Frequency Range
    350-5850 MHz
  • Maximum Power
    500 W
  • Maximum VSWR
    1.25:1
  • Nominal Coupling
    20 dB
  • PIM Typical
    -161 dBc
  • RF Connectors
    N Female
  • Item Height
    1.6 in
  • Qty/ Uom
    1 Each
  • Manufacturer
    Microlab/FXR
  • Item Length
    5.52 in
