32-Channel 896–960 MHz Control Station Combiner, 5RU

Reduce the number of antennas needed with this dbSpectra control station combiner. It funtions as both a combiner and multicoupler for either trunked or conventional mobile radio systems. The overall system port-to-port isolation can be increased using this combiner for applications where individual radio antennas do not provide enough spatial RF isolation, thus removing all the guesswork.

Features:

• Separate transmit and receive antennas
• Low profile building block modules
• Transmit and receive on each radio port
• Enables combining of control stations
• 50-Watt input per channel (continuos)
• Amplifier for receive signals
• Analog or digital radio compatible

Specifications:

• Transmitter loss: 19.5 dB
• Receiver gain (with amplifier): -8 dB
• Receiver loss (without amplifier): 20 dB
• Rack height: 5RU
