Active DAS Tray Point of Interface, PS700 LTE

  • TESSCO SKU: 584343
  • QTY/UOM: 1 EACH
  • UPC: 646444720106
  • MFG PART #: TDTPOI-7FL-D

JMA Wireless TDTPOI-7FL-D Active DAS Tray Point of Interface, Public Safey 700 LTE 758-775MHz, UL: 788-805MHz, Dual. Teko DAS Tray Point of Interface modules (TDTPOI) are flexible single-band and single-operator RF High Power interfaces used in Optical DAS to directly (no external directional coupler nor load needed) interface up to 2 Base Stations, either duplex or simplex, with or without diversity, SISO or MIMO 2x2. The High-power POI DAS Tray utilizes a small footprint for Base Station to DAS Master Units utilizing a common sub-rack can reduce space requirements vs. passive trays as much as 75%. Optical Systems can be equipped with one DAS Tray module or more to make multiple configurations available. TDTPOI are also equipped with SW-settable attenuators for Downlink/Uplink level adjustment and power meter/limiter to control the input power level. Managed as a single system it enables remote optimization of the site parameters, provides alarming for base station failures.

Technical Specs

  • Media Converter Connectors
    SC/APC
  • Description
    Active DAS Tray Point of Interface, Public Safey 700 LTE 758-775MHz, UL: 788-805MHz, Dual. Teko DAS Tray Point of Interface modules (TDTPOI) are flexible single-band and single-operator RF High Power interfaces used in Optical DAS to directly (no external directional coupler nor load needed) interface up to 2 Base Stations, either duplex or simplex, with or without diversity, SISO or MIMO 2x2. The High-power POI DAS Tray utilizes a small footprint for Base Station to DAS Master Units utilizing a common sub-rack can reduce space requirements vs. passive trays as much as 75%. Optical Systems can be equipped with one DAS Tray module or more to make multiple configurations available. TDTPOI are also equipped with SW-settable attenuators for Downlink/Uplink level adjustment and power meter/limiter to control the input power level. Managed as a single system it enables remote optimization of the site parameters, provides alarming for base station failures.
  • Media Transport
    Single-Mode Fiber
  • Qty/ Uom
    1 Each
  • Manufacturer
    JMA Wireless
