Indoor Master Unit EAWS RF Module with 4.3-10 Female Connectors

Comba's master unit EAWS RF module with 4.3-10 Female connectors. This RF module is IP30 rated.

Specifications:

• 1710 - 1755 MHz uplink
• 2110 - 2155 MHz downlink
• 45 MHz operating bandwidth
• -25 dBm uplink output power
• 30 dBm maximum input RF power at master unit
• 0°C to +40°C operating temperature
• Up to 85% relaxtive humidity

Features:

• Independent gain control for each RF source
• Supports both simplex and duplex
• 4.3-10 RF connectors for superior PIM performance

Dimension Diameter, Height: 1.5 x 7.3 x 11.8 in | Weight: 2.2 lb
